Fonksiyon |
Ölçüm aralığı |
Doğruluk |
|
DC Gerilim |
600,0 V … 1000,0 V |
±(0.8% of reading + 5 digits) |
|
AC Gerilim
(50 Hz ... 400 Hz)
|
600,0 V ... 1000,0 V |
±(0.8% of reading + 5 digits) --±(10% of reading + 5 digits) |
|
CREST (Tepe-Tut) |
Accuracy: Add 250 digits to specified accuracy for changes > 5ms |
|
Audible Continuity Tester |
Audible Threshold: 10 Ω - 250 Ω
Tepki Süresi: 32 ms yak.
|
|
Direnç |
600,0 Ω, 6.000 kΩ, 60,00 kΩ |
±(1.0% of reading + 5 digits) |
|
Kapasitans |
200.0 μF, 2500 μF |
±(2.0% of reading + 4 digits) |
|
Diyot Test Cihazı |
2.000 V |
±(1.5% of reading + 5 digits) |
|
AmpTipTM clamp-on ACA
(40 Hz … 400 Hz)
|
00.00 A … 60.00 A |
From ±(1.5% of reading + 5 digits) to ±(3.0% of reading + 5 digits) |
|
Regular Clamp-on ACA
(40 Hz … 400 Hz)
|
60.00 A … 1000 A |
From ±(1.8% of reading + 5 digits) to ±(2.2% of reading + 5 digits) |
|
Hz Line Level Frequency |
5.00 Hz … 999.9 Hz |
±(1.0% of reading + 5 digits) |
|
Non-Contact EF-Detection |
20 V … 440 V |
Tolerance: 10 V … 1000 V |
|
Algılama Frekansı |
50/60Hz |
|
Geçici koruma |
8.0 kV (1.2/50 µs surge) |
|
Aşırı Yük Koruması |
Current & Hz functions via jaws: 1000 ADC/AAC rms at < 400 Hz
Voltage & 3-Phase Rotation functions via terminals: 1100 VDC/VAC rms
Other functions via terminals: 1000 VDC/VAC rms
|
|
Güç kaynağı |
1.5 V AAA Size battery X 2 |
|
Güç tüketimi |
4.3 mA |
|
Boyutlar(LxWxH) |
258 x 94 x 44 mm |
|
Ağırılık |
312 g |
|
Jaw opening & Conductor diameter |
51 mm max |
