AC Current
|
41.99 to 1000 A, 3 ranges (50 to 60 Hz, Average rectified), Basic accuracy: ±1.5 % rdg. ±5 dgt.
|
|
DC Voltage
|
419.9 mV to 600 V, 5 ranges, Basic accuracy: ±1.0 % rdg. ±3 dgt.
|
|
AC Voltage
|
4.199 V to 600 V, 4 ranges (45 to 500 Hz, Average rectified), Basic accuracy: ±1.8 % rdg. ±7 dgt.
|
|
Crest factor
|
N/A
|
|
Resistance
|
419.9 Ω to 41.99 MΩ, 6 ranges, Basic accuracy: ±2 % rdg. ±4 dgt.
|
|
Other functions
|
Continuity: Buzzer sounds at 50 Ω ±40 Ω or less, Data hold, Auto power save, Drop-proof from height of 1 meter
|
|
Display
|
LCD, max. 4199 dgt., Display refresh rate: 400 ms
|
|
Environmental protection
|
IP40 dustproof and waterproof
|
|
Power supply
|
Coin type lithium battery (CR2032) ×1, Continuous use 120 hours
|
|
Core jaw dia.
|
φ 33 mm (1.30 in)
|
|
Dimensions and mass
|
57 mm (2.24 in) W × 175 mm (6.89 in) H × 16 mm (0.63 in) D, 100 g (3.5 oz)
|
|
Accessories
|
CARRYING CASE 9398 ×1, TEST LEAD L9208 ×1, Coin type lithium battery (CR2032) ×1, Instruction manual ×1
|
