Measuring Range
|
Resolution
|
Accuracy
|
|
Earth continuity (200 mA in to 2.00 Ω)
|
|
0.00 Ω to 19.99 Ω
20.0 Ω to 199.9 Ω
200 Ω to 1999 Ω
|
0.01 Ω
0.1 Ω
1 Ω
|
± (5 % of reading + 3 digits)
Indication only
Indication only
|
|
Insulation resistance, Insulation – S resistance (250 VDC, 500 VDC)
|
|
0.00 MΩ to 19.99 MΩ
20.0 MΩ to 49.9 MΩ
50.0 MΩ to 199.9 MΩ
|
0.01 MΩ
0.1 MΩ
0.1 MΩ
|
±(5 % of reading + 3 digits)
±(5 % of reading + 3 digits)
Indication only
|
|
Differential leakage current (230 VAC)
|
|
0.00 mA to 19.99 mA
|
0.01 mA
|
±(5 % of reading + 5 digits)
|
|
Touch leakage current (230 VAC)
|
|
0.00 mA to 7.0 mA
|
0.01 mA
|
±(10 % of reading + 5 digits)
|
|
Substitute leakage current (30 VAC)
|
|
0.00 mA to 9.99 mA
10.0 mA to 20.0 mA
|
0.01 mA
0.1 mA
|
±(5 % of reading + 3 digits)
±(5 % of reading + 3 digits)
|
|
(P)RCD testing (10 mA, 15 mA, 30 mA)
|
|
0 ms to 300 ms (½xI∆N)
0 ms to 300 ms (I∆N)
0 ms to 40 ms (5xI∆N)
|
0.1 ms
0.1 ms
0.1 ms
|
±3 ms
±3 ms
±1 ms
|
|
Power measurement (230 VAC)
|
|
0.00 kVA to 4.00 kVA
|
0.01 kVA
|
±(5 % of reading + 3 digits)
|
|
Voltage TRMS measurement
|
|
80 to 300 V
|
1 V
|
±(2 % of reading + 2 digits)
|
|
Clamp current
|
|
0.00 mA to 9.99 mA
10.0 mA to 99.9 mA
100 mA to 999 mA
1.00 A to 9.99 A
10.0 A to 16.0 A
|
0.01 mA
0.1 mA
1 mA
0.01 A
0.1 A
|
±(5 % of reading + 10 digits)
±(5 % of reading + 5 digits)
±(5 % of reading + 5 digits)
±(5 % of reading + 5 digits)
±(5 % of reading + 5 digits)
|
|
General data
|
|
Power supply voltage
|
9 VDC (6x1.5 V battery or accu, size AA), 230 VAC
|
|
Operation
|
10 h
|
|
Working temperature range
|
0 °C to 40 °C
|
|
Maximum relative humidity
|
95 % RH (0 °C to 40 °C), non-condensing
|
|
Display
|
128 x 64 dots matrix display with backlight
|
|
Memory
|
1500 memory locations
|
|
Communication port
|
RS232 (PS/2 connector, female),
USB (connector Typ B)
|
|
Overvoltage category
|
CAT II / 300 V
|
|
Protection classification
|
Double insulation
|
|
Protection degree
|
case IP 40 /connectors IP 20
|
|
Dimensions (w x h x d)
|
14 cm x 8 cm x 23 cm
|
|
Weight
|
1,2 kg
|
